HM10

Use

HM10 dies are used for hot-melt product application on different support materials.

Features

• Contact coating die with rotating bar
• Width range between 500 and 3000 mm
• Flexible upper lip
• Rotating bar bending adjustment
• Weight range between 12 and 200 gr/m2
• Removable lower lip for deckels application: FG option available

Technical detail

Melt channel surface: hard-chrome plated and mirro-finished surface

Finish:  channel - Ra 0,04-0,08

Lips:    Ra 0,02-0,04

Standard production Aisi P20 (W. Nr. 1.2311) thermal treated steel.

Cartridge heaters placed in the blocks: multipolar plugs.
